Wisycom BFLT1_F1-B-SC-BT2 Portable RF over Fiber Transmitter
Wisycom BFLT1_F1-B-SC-BT2 Portable RF over Fiber Transmitter
SoundPro Item: 150836 | Part Number: BFLR1
Usually ships in 5-7 business days
- Monitor & control through Bluetooth to adjust parameters in real time (Wisycom BT App)
- Wide RF band: 170-1260 MHz
- Operating voltage range: 9 ÷ 18 Vdc
- 2 RGB LEDs for RF overload and system status indication
- Easy configuration thru an high contrast OLED white display and 4 key navigation buttons
- remote power supply from the RF connector (on ANT mode)
- DC power for external amplifier 12V 200mA for PAW or LBP (on IFB mode)
The Wisycom BFLT1 is an RF over Fiber transmitter. The BFLT1 can work in Antenna Mode for placement in a remote area to send signal RF back to local area with minimal loss. The BFLT1 can also be set to IFB mode, allowing the unit to work with the MTK982 and send low power single channel of IFB/IEM signal to a remote area. Once the signal reaches the remote area the PAW can be used to bring the signal up to a working level. The BFLT1 features a 4mW (6dBm) laser, allowing for coverage miles away. The BFLT1 has 20 bandpass filter options, and a 1MHz step software tunable filter to increase RF robustness in any environment. The BFLT1 offers a 12V 150mA output for powering active antennas in remote areas. Using the Wisycom BT app for iOS and Android, remote control and monitor all the settings of the BFLT1, or use the onboard navigation buttons and high contrast OLED display. The BFLT1 features SC/APC and BNC connectors for easy connection.
- Frequency ranges170 - 1260 MHz
- Filter Range
- Selectable Modes:
- Tunable - 470-758 MHz, 40MHz of BW
- Fix 1 - 940-960 MHz (US)
- Fix 2 - 17 Selectable Band Pass Filters
- Connector
- Input: BNC-F
- Output: Single Mode SC/APC
- Impedance50 Ω
- DisplayHigh contrast OLED white display (128 x 64 pixels)
- Power supply9 - 18 Vdc
- Temperature Range-10 - +55 °C
- Antenna Booster Powering+12Vdc, 150mA max
- Power ConsumptionBFLT1: 2 W (DC antenna booster OFF) - 3,5 W (DC antenna booster ON)
- Optical Power6dBm [4mW]
- Wavelength1550 nm
