- Transducer TypeCondenser
- Polar PatternOmnidirectional
- Frequency Response30 Hz - 20 kHz
- Output Impedance
- Phantom: 200Ω
- Battery: 270Ω
- Low Frequency Roll Off 80 Hz, 18 dB/octave
- Open Circuit Sensitivity Phantom-44 dB (6.3 mV) re 1V at 1 Pa
- Battery-46 dB (5.0 mV) re 1V at 1 Pa
- Maximum Input Sound Level
- Phantom: 135 dB SPL, 1 kHz at 1% T.H.D.
- Battery: 121 dB SPL, 1 kHz at 1% T.H.D.
- Dynamic Range
- Phantom: 107 dB, 1 kHz at Max SPL
- Battery: 93 dB, 1 kHz at Max SPL
- Signal-to-Noise Ratio 66 dB, 1 kHz at 1 Pa
- Phantom Power Requirements 11-52V DC, 2 mA typical
- Battery Type 1.5V AA/UM3
- Battery Current/Life 0.4 mA / 1200 hours typical (alkaline)
- Switches Off, on-flat, on-roll-off
- Weight (Microphone) 2.8 g (0.1 oz)
- Weight (Power Module) 139 g (4.9 oz)
- WeightMicrophone : 2.8 g (0.1 oz) - Power Module : 139 g (4.9 oz)
- Cable 1.8 m (6') long (permanently attached to microphone), 2.6 mm (0.10") diameter, 2-conductor, shielded cable with TA3F-type connector
- Dimensions Microphone: 25.0 mm (0.98") long, 10.2 mm (0.40") diameter; Power Module: 84 mm (3.31") H x 63 mm (2.48") W x 22 mm (0.87") D; Microphone: 25 mm (0.98") long, 10.2 mm (0.4") diameter
- Output Connector (Power Module) Integral 3-pin XLRM-type
- Output Connector Integral 3-pin XLRM-type (on Power Module)
