- Connections
- SDI Video Input: 1 x HD/Ultra HD 3G-SDI via BNC
- Power Input: 1 x 4 pin XLR 12V
- Screen Dimensions: 7" 1920 x 1200 resolution
- Screen Type: 7" high brightness TFT LCD
- Screen Brightness: 2000 nits
- Computer Interface: 1 x USB type C connector for initial setup and software updates via Blackmagic Camera Setup software
- SDI Video Standards
- HD Format Support
- 720p50, 720p59.94, 720p60
- 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
- 1080i50, 1080i59.94, 1080i60
- SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 425M 2084
- Video Sampling: 4:2:2 YUV
- Color Precision: 10-bit
- Color Space: REC 601, REC 709
- Multiple Rate support: SDI switches between 1.5 Gb/s HD and 3.0 Gb/s 60P HD
- HD Format Support
- Monitor Features
- Controls: Dial, knobs and customizable function buttons for settings, short cut features and navigating menus
- Handles: Built in grab handles for positioning the monitor independently from the camera.
- Position Adjustment Options: Variable tension pivot points for articulated arm and grab handles with forward, backward, up, down, pan and tilt adjustments
- Mounting Options: Quick release V-lock mounting bracket for attaching viewfinder to URSA Mini handle
- Tally: Large LED tally light with customizable perspex camera numbers
- Metadata Support: Detects camera information embedded in the SDI signal including status information, frame guides, focus peaking, tally, and more
- Screen Interface: On screen meters and status information including Camera ID, resolution, frames per second, shutter speed, gain, white balance, camera battery level, and more
- Operating Systems
- Mac 10.14 Mojave
- Mac 10.15 Catalina or later
- Windows 10
- Power Requirements12V power input via 4 pin XLR connected via URSA Mini 12v power output
- Environmental Specifications
- Operating Temperature: 0° to 40° C (32° to 104° F)
- Storage Temperature: -20° to 60° C (-4° to 140° F)
- Relative Humidity: 0% to 90% non-condensing
- Dimensions (WxH)11.97x9.17"
- Weight5.27 lbs
