- System Performance
- Frequency Response (–3 dB): 1 45 Hz to 16 kHz
- Frequency Range (–10 dB): 33 Hz to 18 kHz
- Nominal Vertical Coverage: Pattern 40°
- Vertical Beam Type: C-shape
- Nominal Horizontal Coverage Pattern: 180°
- Calculated Maximum SPL @ 1 m, continuous: 112 dB
- Calculated Maximum SPL @ 1 m, peak: 118 dB
- Crossover: 200 Hz
- Transducers
- Low Frequency: 1 × RaceTrack low-frequency driver 7" x 13"
- Low Frequency Voice Coil Size: 2"
- High / Mid Frequency 8 × Articulated: 2" drivers
- High / Mid Frequency Voice Coil Size: 3/4"
- Driver Protection: Dynamic limiting
- Amplification
- Type: Two-channel, Class D
- Low Frequency Amp Channel: 240 W
- High / Mid Frequency Amp Channel: 60 W
- Onboard Mixer
- Channels: Three
- Channel 1 & 2 Input: Audio Type
- Combination XLR or 1/4" TRS connector (mic/instrument/line)
- Channel 1 & 2 Input: Input Impedance
- 10 KΩ (XLR); 2 MΩ (TRS)
- Channel 1 & 2 Input: Trim
- 0 dB, 12 dB, 24 dB, 36 dB, and 45 dB analog gain steps automatically selected and compensated by DSP
- Channel 1 & 2 Input: Channel Gain
- –100 dB to +75 dB (XLR); –115 dB to +60 dB (TRS); from input to driver, controlled by volume knob
- Channel 1 & 2 Input: Max Input Signal
- +10 dBu (XLR); +24 dBu (TRS)
- Channel 3 Input: Audio Type
- 1/8" TRS (stereo-summed, line), 1/4" TRS (line), Bluetooth® audio streaming
- Channel 3 Input: Input Impedance
- 40 KΩ (3.5 mm); 200 KΩ (TRS)
- Channel 3 Input: Channel Gain
- –105 dB to +50 dB (3.5 mm); –115 dB to +40 dB (TRS); from input to driver, controlled by volume knob
- Channel 3 Input: Max Input Signal
- +11.7 dBu (3.5 mm); +24 dBu (TRS)
- ToneMatch: Audio Type
- RJ-45 connector for ToneMatch cable connection, providing digital audio and power connection for the optional T4S/T8S ToneMatch Mixer
- Output: Audio Type
- XLR connector, line level, full-frequency bandwidth
- Bluetooth Enabled: Yes
- Bluetooth Types: AAC or SBC for audio streaming, LE for system control
- Channel Controls: 3 digital rotary encoders
- Phantom Power: Channel 1 & 2
- AC Power
- AC Power Input: 100–240 VAC (±15%, 50/60 Hz)
- Electrical Type Input: IEC
- Initial turn on inrush current: 15.8 A at 120 V; 30.1 A at 230 V
- Inrush current after AC mains interruption of 5 s: 1.2 A at 120 V; 19.4 A at 230 V
- Physical
- Color: Black
- Enclosures Material
- Power stand: High-impact polypropylene
- Extension & Array: High-impact ABS
- Grille Material: Powder-coated perforated steel
- Product Dimensions (H × W × D): 78.7 × 12.5 × 17.9 inches (2000 × 317 × 456 mm)
- Shipping Dimensions (H × W × D): 37.4 × 15.75 × 24.8 inches (950 × 400 × 630 mm)
- Net Weight: 38.2 lbs (17.4 kg)
- Shipping Weight: 47.2 lbs (21.4 kg)
