- Operating ModeSingle
- Operating EnvironmentIndoor or Weather-Resistant Outdoor
- Operating Range[2] 38 Hz to 148 Hz
- Transducers 1 x 12" (305mm) double-treated cones with 4" (102mm) voice coil, demodulation ring, neodymium construction
- Continuous Power Handling [3] @ Nominal Impedance Single Amp: 89V; 1000W @ 4 ohms (4000W peak)
- Nominal Sensitivity[4]
- Half Space: 95 dB @ 1W; 95 dB @ 2.83V
- Whole Space: 89 dB @ 1W; 89 dB @ 2.83V
- Nominal Maximum SPL[5]
- Half Space Peak: 131 dB; Continuous: 125 dB
- Whole Space Peak: 125 dB; Continuous: 119 dB
- Equalized Sensitivity[6]
- Half Space: 94 dB @ 1W; 94 dB @ 2.83V
- Whole Space: 88 dB @ 1W; 88 dB @ 2.83V
- Equalized Maximum SPL[7]
- Half Space Peak: 130 dB; Continuous: 124 dB
- Whole Space Peak: 124 dB; Continuous: 118 dB
- Recommended AmplifiersSingle Amp: 1000W - 2000W @ 4 ohms, (75V - 106V)
- Physical
- Input Connection: (2) Screw terminal blocks (4-position)
- Mounting Points: (24) M10 threaded rigging points Indoor; (22 in Outdoor model)
- Environmental: Outdoor: IP55W per IEC 60529, MIL-STD-810G
- Weight: 58 lbs (26.3 kg) subwoofer only
- Dimensions (HxWxD) 14.3x14.5x21" (363x368x533 mm)
