DAS Audio VANTEC-18 Passive Subwoofer
DAS Audio VANTEC-18 Passive Subwoofer
$1,289.00

DAS Audio VANTEC-18 Passive Subwoofer

SoundPro Item: 86154
MPN: VANTEC-18
MSRP: $1,800.60
$1,289.00
Add to Wish List

Account manager
Contact an Account Manager for your personalized price

The VANTEC-18 bass system incorporates the legendary 18LX-low frequency transducer with a 4" voice coil mounted as direct radiator into a bass reflex cabinet. The loudspeaker is protected by a rugged steel grille sealed against corrosion using a powder coat finish.

The VANTEC-18 is designed for use in biamped systems. A top located pole mount socket permits mounting full range systems above the Vantec-18 and two bar handles makes moving easy.

DAS Audio VANTEC-18 Features

  • Bass-reflex subwoofer system
  • 18LX long excursion transducer
  • Precise and powerful bass reproduction
  • Top located pole mount socket
  • Recommended amplifier: PA-2700
  • Recommended processor: DSP-226
  • VANTEC-18 passive subwoofer1
  • Frequency range (-10dB)45Hz - 138Hz
  • Nominal impedance8 ohms
  • Power handling
    • RMS: 1000W
    • Peak: 4000W
  • On-axis sensitivity98dB SPL (1W/1m)
  • Max SPL (at 1m)134dB
  • Audio input connector1x speakON NL4
  • Audio output connector1x speakON NL4
  • LF driver18LX
  • Constructionbirch plywood, black ISO-flex painted
  • RiggingM10 rigging points
  • Dimensions (HxWxD)28.3" x 21.5" x 25.8"
  • Weight99.2 pounds (45 kg)
