Specifications
Acoustical data
Frequency Response [-10dB]: 60 - 20.000 Hz
Frequency Response [-6dB]: 70 - 19.000 Hz
Max SPL: 125 dB
HF: 1"
Directivity: 90 x 70°
Horn:Rotatable CD Horn
LF: 10"
Frequency Response [-6dB]: 70 - 19.000 Hz
Max SPL: 125 dB
HF: 1"
Directivity: 90 x 70°
Horn:Rotatable CD Horn
LF: 10"
Amplifier
Amp Technology: Digipro G2
Amp Class: Class-D
Peak Power: 800 W
PRG Power: 400 W
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Processed
Crossover Frequency LF-HF: 2050 Hz
Slope LF-HF: 24 dB/Octave
System Presets: Flat, Processed
Slope LF-HF: 24 dB/Octave
Mechanics
Housing: MDF
Angles Up: Monitor use 40°
Handles: 1x top side
Rigging points: 12 x M8
Pole Mount: D36 mm
Angles Up: Monitor use 40°
Handles: 1x top side
Rigging points: 12 x M8
Pole Mount: D36 mm
Dimensions (W X H x D)
300 mm (11.8 in) x 480 mm (18.9 in) x 300 mm (11.8 in)
Weight: 13.5 kg (29.76 lbs)
Weight: 13.5 kg (29.76 lbs)
