JBL 305P MkII 5-Inch Powered Studio Monitor
JBL 305P MkII 5-Inch Powered Studio Monitor
SoundPro Item: 25568 | Part Number: 305PMKII
Usually ships in 5-7 business days
- 3-position HF Trim switch
- Patented Slip Stream™ low-frequency port
- Dual integrated, sutom Class-D amplifiers
- Flexible connectivity
- Engineered to JBL Linear Spatial Reference design criteria
- Strenuous JBL 100-hour full-power test
The next-generation JBL 305P MkII powered studio monitor makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers, JBL 305P MkII offers stunning detail, precise imaging, a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace. Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors and sporting a sleek, modern design, JBL 305P MkII delivers outstanding performance and an enjoyable mix experience at an accessible price.
- LF Driver Size5 inches (127 mm)
- HF Driver Size1 inch (25 mm)
- HF Driver TypeSoft dome
- Crossover1725Hz 4th order acoustic Linkwitz-Riley
- Power ConfigurationBi-amplified
- HF Driver Power Amp41 W Class D
- LF Driver Power Amp41 W Class D
- Frequency Response49Hz – 20kHz (±3dB)
- Frequency Range43Hz – 20kHz (-10dB)
- Low Frequency Extension43Hz (-10dB)
- Maximum Continuous SPL94dB
- Maximum Peak SPL108dB
- Maximum Peak Input Level+6dBV / +20.3dBu (-10dBV / +4dBu)
- System Distortion Criteria<10% THD at maximum output with full compressor / limiter engagement
- Electrical Distortion Criteria0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output
- Signal to Noise Ratio75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output
- Coverage Pattern120° x 90° (horizontal x vertical)
- HF Trim Control-2dB, 0dB, +2dB
- Boundary EQLF Shelf @ 50Hz
- AC Input Voltage100 – 240VAC (±10%), 50 / 60Hz
