- Acoustical
- Frequency Range70 Hz - 15 kHz (-3 dB); 63 Hz-17 kHz (-10 dB)
- Coverage Pattern (-6 dB)
- Horizontal: 120 degrees nominal (500 Hz-16 kHz)
- Vertical: Varies with array size and configuration
- Maximum Peak Output: 134 dB
- System Type : Line Array, two-way active
- Transducers
- Low Frequency : (2) JBL 2186G, 6.5 in diameter, dual 2.0 in diameter voice coil, neodymium Differential Drive® High Frequency : (1) JBL 2432H-3, 1.5 in exit neodymium compression driver with 3 in voice coil
- Audio Input
- Input Type : Balanced line level
- Connectors : (2) Neutrik XLR (IN/OUT)
- Nominal Input Sensitivity : +6 dBu (system starts limiting with broadband noise and music)
- Maximum Input Level : 21 dBu
- Input Impedance : 100 kΩ
- DSP
- Sample Rate : 48 kHz
- Bit Depth : 24 bit
- Networking
- Type: TCP/IP
- Protocol: Harman HControl
- Speed: Dual 100 Mbps ports
- Connectors: (2) Neutrik etherCON®
- AC Power
- Voltage Range
- Nominal: 100-240 VAC, 50/60 Hz
- Limits: 80-260 VAC, 50/60 Hz
- Connectors : Dual (IN/OUT) Neutrik powerCON TRUE1 TOP®
- Voltage Range
- Current Draw
- 120V, 208V, 240V
- Standby: 0.2A, 0.1A, 0.1A
- Idle: 0.3A, 0.2A, 0.2A
- Continuous: 1.3A, 0.8A, 0.7A
- Maximum Instantaneous Peak: 7.0A, 5.4A, 4.7A
- Peak Inrush: 2.2A, 3.6A, 4.3A
- Physical
- Enclosure: Polypropylene, four integral recessed handholds
- IP Rating: IP54
- Suspension: Three-point captive suspension plates, quick release pins, steel with anti-corrosion coating
- Grille: Powder coated 1.5 mm (16-gauge) hex perforated steel with acoustically transparent black cloth backing
- Dimensions (HxWxD): 9.5x19.9x16.5 in (243x507x420 mm)
- Net Weight: 37 lbs (16.8 kg)
