- Power Rating 800 W / 1600 W / 3200W
- Frequency Range (-10dB) 60 Hz - 20 kHz
- Dimensions (H x W x D) 629 x 432 x 324 mm (375 mm stage height) 24.75 x 17 x 12.75 in (14.75" stage height)
- Coverage Pattern (-6 dB) 50° x 90° nominal
- Crossover Modes Passive / Bi-amp
- Crossover Frequency 1.1 kHz
- Maximum SPL (1m) 127 dB SPL continuous (133 dB SPL peak)
- Sensitivity 98 dB SPL
- LF Driver 1 x JBL 2265H 380 mm (15 in) Differential Drive® woofer 8 Ohms
- HF Driver 1 x JBL 2453H-SL, 38 mm (1.5 in) exit compression driver, 100 mm (4 in) voice coil and neodymium magnet
- Nominal Impedance 8 ohms
- Active Tunings Tunings available at www.jblpro.com
- Enclosure Symmetrical stage monitor, 15/18 mm, plywood
- Finish Black DuraFlex™ finish
- Grille Powder coated, black, 16 gauge perforated steel with acoustically transparent black screen backing
- Inputs Neutrik® Speakon® NL-4 (x2), one on each end
- Net Weight (each) 21 kg (46 lb)
- Outputs 1 x XLR
