- Typeactive
- Max. SPL (peak)120dB
- Frequency Response50 - 20,000Hz
- Dispersion (HxV)120° x 20°
- Battery
- Rechargeable Batteries: 28,8V / 3200mAh
- Battery Technology: lithium-ion
- Battery Operation Time (at max load): 12 hours @ 98 dB (Lounge), 4 hours at 120 dB (DJ mode), 6 h @ 104 dB (Live music)
- Charging Time: 1.5 hours up to 80%, 2 hours up to 100%
- Woofer Characteristics
- Low/Mid Driver Dimensions: 8"
- Woofer Size: 8"
- Woofer Voice Coil: 2"
- Cabinet Construction: Bass Reflex
- Cabinet Material: ABS plastic
- Subwoofer Dimensions (WxHxD): 12.01" x 15.95" x 15.55"
- Subwoofer Weight: 19.62 pounds
- Mid / Hi System
- Midrange Size: 4 x 3"
- Midrange Voice Coil: 1"
- Mid / Hi System Impedance: 4Ω
- Loudspeaker Inputs: 1
- Speaker Input Connections: custom-made multipin
- Cabinet Construction Mid/High: closed
- Mid / Hi System Cabinet Material: ABS plastic
- Mid / Hi System Dimensions (WxHxD): 3.23" x 21.06" x 4.13"
- Mid / Hi System Weight: 7.72 pounds
- Amplifier Module (integrated in subwoofer)
- Amplifier: Class D
- Amplifier Output System
- RMS: 200W
- Peak: 800W
- Operating Voltage: switching power supply
- Operating Voltage: 100 V AC - 240 V AC, 50 - 60 Hz, 200 V AC - 240 V AC, 50 - 60 Hz (Automatic conversion)
- Power Consumption: 300W
- Line Inputs: 2 x stereoAmplifier Module (integrated in subwoofer)
- Line Input Connectors: 6.3 mm jack, XLR
- Mic Inputs: 1
- Mic Inputs: 6.3 mm jack, XLR
- MP3 Inputs: 1
- MP3 Input Connectors: 3.5 mm jack
- Hi-Z Inputs: 1
- Hi-Z Input Connectors: 6.3 mm jack
- Loudspeaker Outputs: 1
- Speaker Output Connections: custom-made multipin
- DSP Characteristics
- Bit Depth AD/DA Converter: 24 / 24 bit
- Internal Sampling Frequency: 48 kHz
- Overall Height78.15"
- Weight27.33 pounds
