- Frequency Response40Hz - 20kHz (-10 dB); 44Hz - 20kHz (-3 dB)
- Coverage (HxV)90° x 60°
- Max. SPL Peak136 dB
- Monitor Angle45°
- Transducers
- Low Frequency: 15" with ferrite
- High Frequency: 1.4" polymer compression driver
- Power Amplifiers
- System Power Amplification, Rated Power: 2000 watts peak
- Low Frequency Power Amplifier
- Rated Power: 1800 watts peak
- Rated THD: <1%
- Design: Class D
- High Frequency Power Amplifier
- Rated Power: 200 watts peak
- Rated THD: <1%
- Design: Class D
- System Processing
- Voicing: 10 speaker modes (5 inside, 5 outside)
- Subwoofer HPF: off, DRM18S, Var
- Input EQ: 3-band
- Delay: 0-100 ms
- Input / Output
- Input Type
- 2x female XLR balanced
- 1/4" balanced
- 1/8" stereo
- Mic-Line Impedance: 20 kΩ balanced
- 1/4" Hi-Z Impedance: 100 kΩ balanced
- Direct Out and Mix Out: male XLR balanced
- Mix Out Impedance: 300 Ω balanced
- Electronic Crossover
- Crossover Type: 24 dB/octave
- Crossover Frequency: 2 kHz
- Line Input Power
- Detachable Line Cord
- ~100 - 240 VAC, 50-60Hz, 110W
- ~220 - 240 VAC, 50-60Hz, 110W
- AC Connector: 3-pin IEC 250 VAC, 10 A male
- Power Supply Type: switchmode
- Construction Features
- Enclosure Material: black polypropylene
- Enclosure Finish: light black texture
- Grille Material: 16-18 gauge perforated steel w/ nylon net backing
- Grille Finish: powder-coated black
- Dimensions (HxWxD): 28.8" x 17.6" x 15.4"
- Weight: 48.9 pounds
