- Frequency Response55Hz - 20kHz (-3 dB); 50Hz - 23kHz (-10 dB)
- Max. Peak SPL126 dB
- Crossover Point3 kHz
- Dispersion (HxV)90° x 80°
- High-Frequency Section
- Compression Driver: 1.4"
- Low-Frequency Section
- Woofer Diameter: 10"
- Power Amplifiers
- System Power Amplification, Rated Power: 500 watts rms, 1000 watts peak
- Low Frequency Power Amplifier
- Rated Power: 400 watts rms, 800 watts peak
- Rated THD: <1%
- Design: Class D
- High Frequency Power Amplifier
- Rated Power: 100 watts rms, 200 watts peak
- Rated THD: <1%
- Design: Class AB
- Input / Output
- Channel 1
- Mic-Line: 8 kΩ balanced
- 1/4" TRS, Wide-Z™: 1 MΩ unbalanced
- Channel 2
- Mic-Line: 8 kΩ balanced
- 1/4" TRS, Wide-Z™: 1 MΩ unbalanced
- RCA: 25 kΩ unbalanced
- Thru: male XLR balanced (Passive when the Ch 1 / Mix switch is in the "out" Ch 1 position; Active when the Ch 1 / Mix switch is in the "in" Mix position)
- Power
- US Detachable Line Cord: 100 - 120 VAC, 50-60Hz, 160W
- AC Connector: 3-pin IEC 250 VAC, 10 A male
- Power Supply Type: switchmode
- Construction Features
- Cabinet: polypropylene
- Finish: black textured finish
- Grille: perforated metal with weather-resistant coating
- Monitor Angle: 50°
- Dimensions (HxWxD): 20.8" x 13.1" x 12.3"
- Weight: 23 pounds
- Mounting Methodsfloor mount, pole mount or fly via optional bracket
