- Transducer TypeCondenser
- Polar PatternSupercardioid
- Frequency Range20 Hz - 20 kHz
- Rated Output Impedance150 ohms
- Sensitivity at 1 kHz into 1 kohm18 mV/Pa ± 1 dB
- Equivalent noise level, CCIR (1)23 dB
- Equivalent noise level, A-weighted (2)12 dB-A
- Maximum SPL for THD 0.5% (3)128 dB
- Maximum SPL for THD 0.5% with preattenuation (4)138 dB
- Signal-to-noise ratio, CCIR (re. 94 dB SPL) (5)71 dB
- Signal-to-noise ratio, A-weighted (re. 94 dB SPL) (6)82 dB
- Maximum output voltage1.3 dBu
- Supply voltage (P48, IEC 61938)48 V ± 4 V
- Current consumption (P48, IEC 61938) 0.8 mA
- Matching connectorXLR 3 F
- Weight145 g
- Diameter21 mm
- Length213 mm
- Notes
- 1) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
- 2) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
- 3) measured as equivalent el. input signal
- 4) measured as equivalent el. input signal
- 5) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
- 6) according to IEC 60268-1; CCIR-weighting acccording to CCIR 468-3, quasi peak; A-weighting according to IEC 61672-1, RMS
