Neutrik NBB75DFGX Grounded UHD BNC Chassis Connector
Neutrik NBB75DFGX Grounded UHD BNC Chassis Connector
$13.48

Neutrik NBB75DFGX Grounded UHD BNC Chassis Connector

(No reviews yet)
SoundPro Item: 109799
MPN: NBB75DFGX
MSRP: $14.98
$13.48
Add to Wish List

Account manager
Contact an Account Manager for your personalized price

Neutrik's UHD BNC chassis connectors offer low return loss values at high frequencies specific for high resolution video signal transmission. The machined brass connector body provides an extremely rugged and non-abrasive connection over long term use and is in addition recessed and therefore well protected in a D-shape housing.

Neutrik NBB75DFGX Features

  • Optimized gold plated cage type center contact for UHD signals as 4K or 8K
  • Swiss antraloy plating
  • Grounded panel mount
  • Standard D-shape housing provides flush mounting and protection from damage
  • Color coding possible
  • Fully compatible with conventional BNC cable connectors
  • Neutrik NBB75DFGX Grounded UHD BNC Chassis Connector1
  • TitleNBB75DFGX
  • Connection TypeBNC 75Ω
  • Gender female
  • Electrical
    • Contact resistance: ≤ 3 mΩ (inner)
    • Contact resistance: ≤ 2 mΩ (outer)
    • Dielectric strength: 1.5 kVdc
    • Impedance: 75Ω
    • Insulation resistance: > 5 GΩ
    • Rated voltage: < 50V
    • VSWR
      • ≤1.06 / >30 dB up to 6 GHz
      • ≤1.13 / >24 dB up to 12 GHz
      • ≤1.22 / >20 dB up to 18 Ghz
    • Signal type: UHD, SDI, Video, AES/EBU, Composit, YUV, RGB, RGBH, RGBHV
  • Mechanical
    • Insertion force: < 25 N
    • Lifetime: > 1000 mating cycles
    • Wiresize: -
    • Locking device: Bayonett
    • Mounting direction: Front mounting
    • Chassis shape: D
  • Material
    • Contacts: Brass (CuZn39Pb3), 0.2 µm AuCo (center contact)
    • Insert: PTFE
    • Shell: Polyacetal (POM) (insulation shell)
    • Shell plating: Antraloy
    • D-shape housing: Zinc diecast (ZnAl4Cu1)
  • Environmental
    • Temperature range: -30°C to +85°C
