- Global
- OLED Display
- Seamless Transitions
- Split Point Crossfades
- 16 banks with 25 programs - 400 locations
- Organize functionality for programs
- Live Mode - 5 Live programs
- Global Transpose: +/- 6 semitones
- Program Transpose: +/- 6 semitones
- Fine-tune: +/-50 cents
- Kbd Touch: 3 velocity response curves
- Triple Sensor keybed with Virtual Hammer Action Technology
- Split functionality with selectable split point and LED indication
- Layer functionality
- Mono Output option
- Dynamic Sustain Pedal action with included Nord Triple Pedal
- USB-MIDI
- Free OS updates
- Piano Section
- 2 independent Layers
- 6 types: grand, upright, electric pianos, digital, layer, clavinet, harpsichord
- Each category can contain up to 20 different models
- 120 Voice Polyphony (stereo/mono pianos)
- Piano Timbre feature with Soft, Mid and Bright settings for acoustic pianos. Dyno 1 and 2 options for electric pianos
- Layer Detune with 3 amounts
- Advanced String Resonance (Gen 2) - adjustable amount
- Selectable Soft Release for Grand, Upright, Electric Pianos and Harpsichord
- Selectable Pedal Noise for Grand, Upright and Electric Pianos 1 - adjustable mount
- Octave Transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)
- Sample Synth Section
- 40+ Voice Polyphony
- Amp envelope with Attack and Decay/Release
- Bright and Soft Timbre options
- Adjustable Vibrato with 3 Delay options
- Unison feature with 3 amounts
- Selectable velocity sensitive low pass filter and dynamic range
- Octave transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)
- Volume controllable with Volume Pedal (not included)
- Memory
- Approx. 2 GB dedicated to the Nord Piano Library
- Approx. 1 GB dedicated to the Nord Sample Library
- Effects Section
- Effect 1
- Pan, Tremolo, Wah and Ring Modulator
- Three selectable depths for the Pan and Tremolo, rate controlled with the Effect 1 Rate knob
- Tremolo, Pan, Ring-Mod and Wah can be controlled with Control Pedal
- Effect 2
- Phaser 1, Phaser 2, Flanger, Chorus 1, Chorus 2 and Vibe
- Two selectable depths for each effect
- Amp Simulations, Comp and EQ
- Comp/Amp - three amp/speaker simulations, Tube Overdrive
- Drive/Compression amount controlled with the Drive knob
- Three band EQ, with sweepable mid. +/- 15 dB gain/attenuation
- Global mode for EQ
- Delay
- Delay Effect with Rate, Amount and Tap-tempo controls
- Ping-pong mode
- Global mode
- Master Effects: dedicated Reverb with Booth, Room, Stage, Hall and Cathedral algorithms. Dark/Bright settings and optional Chorale modulation effect
- Connections
- 2 Audio outputs L & R - ¼", 6,35 mm jacks, unbalanced
- 1 Monitor input - 1/8", 3,5 mm stereo jack
- 1 Headphone output - ¼", 6,35 mm stereo jack
- 1 Sustain Pedal input - ¼", 6,35 mm jack. Use the included Nord Triple Pedal or a momentary pedal
- 1 Volume Pedal input - ¼", 6,35 mm TRS stereo jack. Use a Control/Expression pedal like e.g. Yamaha FC-7, Roland EV-5 etc.
- MIDI In, MIDI Out - 5 pin DIN connectors
- USB - type B connector - for transferring sounds and USB-MIDI
- IEC C14 power connector
- Dimensions50.7" x 13.4" x 4.7"
- Weight40.1 pounds
