Panasonic AW-UE50 4K/30P Ultra Quiet PTZ Camera | Color: Black
Panasonic AW-UE50 4K/30P Ultra Quiet PTZ Camera | Color: Black
SoundPro Item: 132774 | Part Number: AW-UE50KPJ
Regular price
$4,880.00
Regular price
$5,131.20
Sale price
$4,880.00
Unit price
per
MSRP: $5,131.20
| MAP: $4,880.00
Usually ships in 5-7 business days
- 4K 25/30p and 24x Optical Zoom
- New Direct Drive System for improved responsiveness and quietness
- Supports NDI|HX version 2 and SRT*1 protocol
- Excellent system flexibility to achieve smart wiring and smooth operation
The AW-UE50/UE40 supports a compact design to blend in with the surroundings and operates very quietly to permit flexible use in any video shooting locations or conditions.
PTZ cameras enhance visual communication in a variety of applications ranging from online classes to online seminars. The AW-UE50/UE40 offers high security and it is easy to install and operate for capturing stable images, so even people unfamiliar with video shooting or camera operation can utilize it. The excellent flexibility of the product simplifies wiring and operation. Linkage with online conference software or online application is possible, so online video streaming is easy to initiate. The AW-UE50/UE40 is a standard model perfect for people who want to utilize online video streaming more frequently or enhance the quality of online video streaming.
- LENS Motorized Optical 24x zoom, F1.8 to F4.0[f=4.12 mm (5/32 inches) to 98.9 mm (3-29/32 inches);35 mm (1-3/8 inches) equivalent: 25.0 mm (31/32 inches) to 600.0 mm (23-5/8 inches)]
- MINIMUM ILLUMINATION 3 lx (F1.8, 59.94p, 50IRE, 42 dB, without accumulation)
- Zoom
- Optical zoom: 24x• i.Zoom UHD 28x, FHD 36x
- Digital extender zoom: 1.4 x , 2 x
- Horizontal Resolution UHD: 1,500 Typ (Center area)FHD: 1,000 Typ (Center area)
- Gain Selection Auto, 0 dB to 36 dB*3 (Super Gain function equipped : 37 dB to 42 dB)
- WHITE BALANCEATW : 3200 K, 5600 K (ATW Speed 3-stage variables.)• AWB : AWB-A / AWB-B• VAR (selectable between 2000 K and 15000 K by designating a value)
- Storage Temperature -20 °C to 50 °C (-4 °F to 122 °F)
- Current consumption 1.8 A (Supplied AC adaptor), 0.6 A (PoE+ power supply)
- Power Requirements 12 V DC (10.8 V to 13.2 V) (Supplied AC adapter)
- Color separation optical system 1MOS
- Focus Switching between auto and manual
- Focus Distance Entire zooming range: 1200 mm (3.9 ft)Wide end: 100 mm (0.33 ft)
- Gamma HD / Normal / Cinema1 / Cinema2 / Still Like
- Input Connector DC 12 V IN
- Pan/Tilt Operation Speed Speed range: 0.08°/s to 60°/s (Normal mode)*7 - 3 speed modes installedNormal:60°/s, Fast1:90°/s, Fast2:180°/s
- Quietness NC25 or less
- Tilting Range -30°to 90°*8
- Imaging Sensors 1/2.5-type 4K MOS x1
- Frame Mix Auto, 0 dB, 6 dB, 12 dB, 18 dB, 24 dB*4
- Chroma Amount Variability OFF, -99 % to 99 %
- Ambient Operating Humidity 20 % to 90 % (no condensation)
- Finish AW-UE50W: WhiteAW-UE50K: Black
- Image Resolution 1920x1080, 1280x720, 640x360, 320x180
- Note *1:Discontinued Model*2:Will be supported in the future*3:Can be set in 1 dB step increments.*4:Cannot be set when the format is 2160/29.97p, 2160/23.98p, 2160/24p, 2160/25p, 1080/29.97p, 1080/23.98p (59.94i), 1080/29.97PsF, 1080/23.98PsF, 1080/25p, 1080/25PsF.*5:STP (Shielded Twisted Pair) is recommended.*6:To ensure safety, the unit must be secured using the mount bracket supplied.*7:Note that the operating noise may be loud in high speed. If the operating noise is disturbing, use the Normal mode.*8:The main unit may appear in the video depending on the pan/tilt position.*9:Supported OS indicated are for browsers current as of September 2021. See “Service and Support / PASS” for the latest information on browser support.*10:NDI® is a new protocol developed by NewTek, Inc. that supports IP video production workflow.*11:NDI® is a registered trademark of NewTek, Inc. in the United States.*12:In this instance, NDI® is used to indicate low latency with high bandwidth NDI®, NDI®|HX is used to indicate high efficiency low bandwidth NDI®|HX. In the NDI®|HX mode, 4K video signals cannot be output. AW-UE50/AW-UE40 supports NDI®|HX version 2 and Full HD output.*13:For details, please contact a sales representative of Panasonic. To use NDI®|HX, the driver must be installed and activated.*14:Non-synchronous with SDI-OUT
- Panning range ±175°
- Mass Approx. 1.8 kg (3.97 lbs) (excluding ceiling mounting bracket)Approx. 2.05 kg (4.51 lbs) (including ceiling mounting bracket)
- Installation Method Stand-alone (Desktop) or suspended (Hanging)*6
- Controller Supported AW-RP150GJ, AW-RP60GJ, AW-RM50AG, AK-HRP1000*1,2, AK-HRP1005*1,2, AK-HRP1015*2, AK-HRP250*2
- Ambient Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
- Dimensions (WxHxD) 6.299x7.563x6.535" (160x192.1x166 mm), excluding protrusions, cable cover, ceiling mounting bracket)
- Conversion Lens Not supported
- Angle of View Range Horizontal angle of view: 74.1° (wide) to 3.3° (tele)Vertical angle of view: 46.0° (wide) to 1.9° (tele)Diagonal angle of view: 81.8° (wide) to 3.8° (tele)
- Image Streaming Mode JPEG (MJPEG), H.264, H.265, NDI®|HX version 2*10,11,12,13 (H.264)
- Image Transmission setting (JPEG) Frame rate: Maximum 30fpsImage quality (Fine / Normal)
- Image Transmission Setting (H.264) Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
- Transmission Priority Constant bit rate, Frame rate, Best effort
- Frame Rate[60 Hz] 5fps / 15fps / 30fps / 60fps, [50 Hz] 5fps / 12.5fps / 25fps / 50fps
- Max Bit Rate512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps /12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps
- Image Transmission Setting (H.265) Transmission Type: Unicast port (AUTO), Unicast port (MANUAL), Multicast port
- Transmission PriorityConstant bit rate, Frame rate, Best effort
- Frame Rate [60 Hz] 30fps / 60fps, [50 Hz] 25fps / 50fps
- Max Bit Rate512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps /12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps
- Audio Compression Type AAC-LC, 48 kHz / 16 bit / 2ch
- Tally LED display color red / green
- PoE+ IEEE802.3at compliant : DC42 to 57 V (Camera Input)(Software authentication (LLDP) is supported)
- NDI Support NDI®|HX version 2: Upgradable
- Mic/line input
- AAC compatibility (compatible with IP only)
- Φ3.5 mm stereo mini jack: During MIC input
- Input level: -40 dBV (0 dB=1 V/Pa, 1 kHz)
- Supply voltage: 2.5 V±0.5 V (plug-in power compatible)": Input impedance: Approx. 2 kΩ (when plug-in power is turned ON)
- Approx. 20 kΩ (when plug-in power is turned OFF)": During LINE input
- Input level: -10 dBV
- Input impedance: Approx. 3 kΩ
- Input volume variable range: -36 dB to 12 dB (3 dB step)
- Embedded audio output level: -12 dBFS
- Sampling frequency: 48 kHz
- IP connecting cable
- If you have a PoE+ ethernet hub - LAN cable*5 (category 5e or above, straight cable) Max 100 m (328 ft)
- If you don't have a PoE+ ethernet hub - LAN cable*5 (category 5e or above, straight cable) Max 100 m (328 ft)
- AW protocol connecting cable • LAN cable*5 (category 5e or above, straight cable) Max 1000 m (3280 ft)
- Electronic Shutter Speed | 59.94p/59.94i 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- Electronic Shutter Speed | 29.97p 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- Electronic Shutter Speed | 50p/50i 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- Electronic Shutter Speed | 25p 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- Input/Output Connector | LAN LAN terminal for IP control (RJ-45)
- Input/Output Connector | RS-422 CONTROL IN RS422A (RJ-45)
- Windows
- Windows 10
- Windows® Internet Explorer® 11 (32 bit / 64 bit)
- Microsoft Edge
- Google Chrome
- Mac
- Mac OS v11.0.1 / Safari 14.01
- Mac OS v11.0.1 / Google Chrome
- Mac OS v10.15 / Google Chrome
- Mac OS v10.14 / Google Chrome
- Android
- Android OS
- Google Chrome
- Video Output | HDMI
- HDMI 1.4 connector, 4:2:2/10bit
- HDCP is not supported
- Viera Link is not supported
- Electronic Shutter Speed | 23.98p/24p 1/24, 1/48, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
- Synchro Scan | 59.94p/59.94i 60.0 Hz to 7200 Hz
- Synchro Scan | 29.97p 30.0 Hz to 7200 Hz
- Synchro Scan | 23.98p/24p 24.0 Hz to 7200 Hz
- Synchro Scan | 50p/50i 50.0 Hz to 7200 Hz
- Synchro Scan | 25p 25.0 Hz to 7200 Hz
- Output Format | SDI | HD 1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native), 23.98p (over59.94i), 1080/29.97psF, 25psF, 23.98psF, 1080/24p (Just), 23.98p (Native), 720/59.94p, 50p
- Output Format | HDMI | 4K 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Just), 2160/23.98p (Native)
- Output Format | HDMI | HD 1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native), 23.98p (over59.94i), 1080/24p (Just), 23.98p (Native), 720/59.94p, 50p
- Video Output | 3G-SDI OUTSMPTE292M, 424M/ 75 Ω (BNCx1); Level-A/Level-B supported
- iPhone / iPad iOS
- Safari
- iPadOS
- Image Stabilization
- OIS 2-axis
- MENU switching: Select between Off/O.I.S.
- Supported protocol | IPv4 TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, DHCP, DNS, DDNS, NTP, IGMP, ICMP, ARP, RTMP, RTMPS, SRT
- Supported protocol | IPv6 TCP/IP, UDP/IP, HTTP, HTTPS, DNS, NTP, DHCPv6, RTP, MLD, ICMP, ARP, RTMP, SRT
- Supported operating systems and web browsers *9
- Image Resolution | NDI®|HX version 2 1920x1080, 1280x720
- Audio Compression Type | NDI®|HX version 2 AAC-LC, 48 kHz, 16 bit, 2 ch
- F-Number Display Displayed on the AW-RP150GJ and AW-RP60GJ sides
- Menu Display on IP Video Supported*14
- Power LED ON/OFF control
- Tripod Screw Penetration Measures Possible
- Pan/Tilt Mechanical Method New Direct Drive System
- Privacy ModeThe lens surface faces backward when standing by (ON/OFF); Default is OFF
- Image Transmission Setting (NDI®|HX version 2)Transmission Type: Streaming method: TCP/UDP, Unicast/Multicast
