Q-SYS QIO-ML2x2 Network Audio Mic/Line I/O Expander
Q-SYS QIO-ML2x2 Network Audio Mic/Line I/O Expander
SoundPro Item: 132910 | Part Number: QIO-ML2x2
Pricing available upon request
Pricing available upon request
In stock and ready to ship
- Native network audio I/O solution for Q-SYS
- Two (2) mic/line inputs and two (2) line outputs
- Professional, high performance mic/line level inputs (with +48 VDC phantom power) and/or line outputs
- Microphone detection on inputs to enable monitoring, usage statistics and failure notifications
- Power over Ethernet (PoE) capable or daisy-chain up to four QIO expanders on a single network run (with local daisy-chained DC power)
- Simple drag-and-drop integration and comprehensive management via Q-SYS Designer Software and Q-SYS Reflect Enterprise Manager
- Surface- or rack-mountable (1RU, quarter width)
- Includes surface mounting hardware
The Q-SYS QIO Series network audio I/O expanders extend your Q-SYS system's capabilities and enable streamlined interoperability with non-networked audio devices. By separating local I/O from processing hardware, the QIO Series offer modular and easily scalable network I/O to support your desired topology. There are three models that offer mic/line connectivity to integrate consumer or professional audio devices into your Q-SYS system.
- ConnectivityTwo (2) mic/line inputs and two (2) line outputs
- Maximum input level+24 dBu
- Preamplifier gain range0 dB to 60 dB
- Phantom power+48 VDC
- Equivalent Input Noise< -120 dBu, no weighting @ 20 Hz to 20 kHz
- Input to input crosstalk @ 1 kHz> 85 dB
- Input Dynamic Range
- @ +24 dBu sensitivity: > 105 dB
- @ +10 dBu sensitivity: > 100 dB
- @ -10 dBu sensitivity: > 95 dB
- @ -36 dBu sensitivity: > 80 dB
- Input impedance5 kΩ single-ended, 10 kΩ balanced
- Output audio range level-36 dBu to +24 dBu
- Output dynamic range108 dB
- Output to output crosstalk @ 1 kHz> 85 dB
- Output Impedance150 Ω to 300 Ω
- Sample rate48 kHz
- Bit Depth24 bit
- External power supply24 VDC nominal, 2.5 A on Euro connector with second connector for daisy-chaining (QIO-PSU power supply sold separately)
- LAN (PoE)Gigabit LAN connection for Q-LAN, PoE
- PoE specificationConforms to IEEE 802.3af Type 1
- LAN (Thru)Ethernet daisy-chaining
- Dimensions8.5 x 4.25 x 1.59 in (215.9 x 108 x 40.4 mm)
- Weight1.72 lb (0.78 kg)
- Mounting optionsSurface- and wall-mountable (hardware included)
Rack-mountable; 1RU, quarter-rack width (QIO-RMK rack kit sold separately) - Ambient operating temperature range0°C to +50°C
- Humidity0% - 85% through 30°C, non-condensing
- Storage temperature-20° to 70°C
