- Audio circuit type Passive, transformer isolated
- Frequency response 20Hz ~ 20KHz (+0/-1dB)
- Dynamic range >137dB
- Gain >-10dB
- Total harmonic distortion 0.003%
- Phase Deviation 0.3° @100Hz; 5° @ 20Hz
- Input Impedance 1600 Ohms
- Output Impedance 1850 Ohms
- Common Mode Rejection Ratio 100dB @60Hz (unbalanced source)
- Equivalent Input Noise >-98dBu Noise plus gain
- Noise -111dBu
- Maximum Input >+26dBu
- Features
- Input pad, 180° polarity reverse, Ground lift
- Input Connectors: XLR
- Output Connectors: 1/4"
- Construction 14 gauge steel chassis and outer shell
- Size (LxWxD) 3.3x5x2" (84x127x48mm)
- Weight 1.55 lbs (720 g)
- Power Passive, no power required
- Conditions For use in dry locations only between 5°C and 40°C
