• RDL TX-A2D Dual Audio Converter - Balanced to Unbalanced
1 1

RDL TX-A2D Dual Audio Converter - Balanced to Unbalanced

RDL TX-A2D Dual Audio Converter - Balanced to Unbalanced

SoundPro Item: 72612 | Part Number: TX-A2D

$150.85
$201.13 $150.85
Your Price Sold out
MSRP: $201.13 | MAP: $150.85

Usually ships in 5-7 business days

  • Unbalanced Audio Outputs from a Stereo Balanced Line
  • Balanced to Unbalanced Conversion
  • Stereo Input to Stereo Output
  • +4 dBu Input Level to -10 dBV Output Level
  • Studio-Quality Transformer Isolation
  • Passive Converter with Output Jacks
Log in or register for YOUR best price

The TX-A2D is the ideal choice in installations requiring passive isolation and level attenuation between a professional balanced line-level stereo source and consumer equipment unbalanced inputs.

The TX-A2D is a complete unbalanced stereo line-level audio output module. The front panel provides a detachable terminal block for connecting each channel of a balanced +4 dBu audio source. The input signals are coupled to two front-panel gold plated phono jacks through studio-quality isolation transformers. Each output is coupled through an attenuation network that produces a nominal -10 dBV level. Shielding is provided by the TX-A2D's heavy duty aluminum enclosure.

Wherever professional format audio signals need to be converted to an unbalanced line level, the TX-A2 and TX-A2D are an ideal choice. Use them individually or in conjunction with other RDL products as part of a complete audio/video system.

View full details
  • Input connector 2Detachable terminal block
  • Input level+4 dBu nominal; +22 dBu max
  • Output connectors (2)Gold plated phono jacks
  • Output level-10 dBV nominal
  • Frequency response (line level)20 Hz to 20 kHz (±0.5 dB)
  • Crosstalk<-80 dB (20 to 20 kHz, ref. -10 dBV); <-90 dB (1 kHz)
  • Total Harmonic Distortion<0.05% (20 Hz to 20 kHz, +4 dBu input); <0.01% (1 kHz)
  • Dimensions3.17" (8.05 cm) W; 1.76" (4.47 cm) H; 2.06" (5.23 cm) D 3.17 x 1.76 x 2.06 in
  • Package Dimensions3.625x4.625x2.125"
  • Shipping Weight0.89 lbs
  • WEEE weight0.737 lbs
  • Ambient Operating Environment0°C to 55°C
