Specifications
Capsule
Capsule Type
Hand-Crafted 1" True Condenser
Polar Pattern
Polar Pattern
Cardioid
Frequency Response
Frequency Range
20 Hz - 20 kHz
Sensitivity And Noise
Sensitivity
30 mV / Pa (-31 dBV)
Equivalent Noise Level
9 dB
Signal To Noise Ratio
85 dB
Dynamic Range And SPL
Max SPL (0 dB Pad)
140 dB (0.5% THD @ 1 kHz)
Max SPL (10 dB Pad)
150 dB (0.5% THD @ 1 kHz)
Max SPL (20 dB Pad)
160 dB (0.5% THD @ 1 kHz)
Dynamic Range (0 dB Pad)
131 dB
Dynamic Range (10 dB Pad)
141 dB
Dynamic Range (20 dB Pad)
151 dB
Filters And Pads
Low-Cut Filter Options
80 Hz, 6 dB/Oct, Switchable; 160 Hz, 6 dB/Oct, Switchable
Attenuation Pad Options
10 dB Switchable; 20 dB Switchable
Electrical
Electrical Impedance
125 Ohms
Recommended Load Impedance
>1 k Ohms
Current Consumption
6.0 mA
Power
48V Phantom Power (P48 According To IEC 61938)
Connectivity
Connector
3-Pin Male XLR
Dimensions
Microphone Diameter
58 mm (2.28")
Microphone Length
169 mm (6.65")
Weight
Microphone Weight
445 g (15.70 oz.)
