Sennheiser ew 500 G4-965 Wireless Handheld Microphone System | Frequency: AW+ (470-558 MHz)
Sennheiser ew 500 G4-965 Wireless Handheld Microphone System | Frequency: AW+ (470-558 MHz)
SoundPro Item: 118387 | Part Number: ew 500 G4-965-AW+
Usually ships in 5-7 business days
- True diversity half-rack receiver in a full-metal housing with intuitive OLED display for full control
- Easy and flexible wireless synchronization between transmitter and receiver via infrared
- Up to 32 compatible channels
- Up to 88 MHz bandwidth with 3520 selectable frequencies, fully tunable in a stable UHF range
- Ethernet connection for Wireless Systems Manager (WSM) control software for advanced frequency coordination in multi-channel setups
- High RF output power (up to 50 mW, adjustable in three steps 10/30/50) depending on country regulations
The ew 500 G4-965 Wireless Handheld Microphone System from Sennheiser is ideal for professional live performances. This set comes with a rugged SKM 500 G4 handheld transmitter, 1 MMK 965-1 capsule, EM 300-500 G4 rackmount receiver, GA3 rack kit, and mic clip.
Offering more sensitivity and clarity, the 865-1 cardioid/supercardioid capsule rejects unwanted stage noise from the sides and rear, so you can capture your vocals while minimizing pick-up of other instruments or sound sources. The handheld mic’s condenser design is characterized by better sound sensitivity than a dynamic mic, enabling it to capture more natural, detailed audio.
- EM 300-500 G4
- Frequency range
- AS: 520 - 558 MHz
- Aw+: 470 - 558 MHz
- Bw: 626 - 698 MHz
- Cw: 718 - 790 MHz
- Dw: 790 - 865 MHz
- GBw: 606 - 678 MHz
- Gw: 558 - 626 MHz
- Gw1: 558 - 608 MHz
- JB: 806 - 810 MHz
- K+: 925 - 937.5 MHz
- Dimensions: Approx. 202x212x43 mm
- Compander: Sennheiser HDX
- THD, total harmonic distortion: ≤0.9%
- Weight: Approx. 980 g
- Audio output
- 6.3 mm jack socket (unbalanced): +12 dBu
- XLR socket (balanced): +18 dBu
- Signal-to-noise ratio: ≥ 115 dBA
- Switching bandwidth: up to 88 MHz
- Peak deviation: ±48 kHz
- Nominal deviation: ±24kHz
- Modulation: Wideband FM
- Power supply: 12 V DC
- Antenna connector: 2 BNC sockets
- Current consumption: 350 mA
- Adjacent channel rejection: Typically ≥ 75 dB
- Intermodulation attenuation: Typically ≥ 70 dB
- Receiving frequency: Max. 3520 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
- RF sensitivity: < 2.5 μV for 52 dBA eff S/N
- Squelch: 5 to 25 dBμV in steps of 2 dB
- Equalizer
- Preset 1: Flat
- Preset 2: Low Cut (-3 dB at 180 Hz)
- Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)
- Preset 4: High Boost (+6 dB at 10 kHz)
- Temperature Range: -10°C to +55°C
- Receiver Principle: True diversity
- Blocking: ≥ 75 dB
- Frequency range
- SKM 500 G4
- Dimensions: Approx. Ø 50x265 mm
- Compander: Sennheiser HDX
- THD, total harmonic distortion: ≤ 0.9 %
- Weight: (incl. batteries) approx. 450 g
- Signal-to-noise ratio: ≥ 115 dBA
- RF output power: switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
- Switching bandwidth: up to 88 MHz
- Peak deviation: ±48kHz
- Nominal deviation: ±24kHz
- Operating time: Typically 8 h
- Modulation: Wideband FM
- Power supply: 2 AA batteries, 1.5V or BA 2015 accupack
- Current consumption
- at nominal voltage: typ. 180 mA
- with transmitter switched off: ≤ 25 µA
- Powering: 3V battery/2.4V rechargeable battery
- Transmission frequency: Max. 3520 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
- AF frequency response: 80–18,000Hz
- Temperature Range: -10°C to +55°C
- Frequency stability: ≤ ±15 ppm
- MMK 965-1
- Frequency response: 40 to 20,000 Hz
- Max. sound pressure level: 144dB
- Transducer principle: externally polarized dual diaphragm condenser microphone
- Weight: 162 g
- Diameter: of diaphragm: 2.54 cm (1")
- Pick-up pattern: cardioid/supercardioid, switchable
- Sensitivity in free field, no load (1kHz): 7.0 mV/Pa
- Equivalent noise level: 18 dB
- Dynamic range: 126 dB(A)
