Sennheiser EW-DX 835-S SET Wireless Microphone Handheld System | Frequency: Q1-9
Sennheiser EW-DX 835-S SET Wireless Microphone Handheld System | Frequency: Q1-9
SoundPro Item: 133281 | Part Number: EW-DX 835-S SET (Q1-9)
In stock and ready to ship
- This wireless microphone handheld system is great for performances and presentations of all kinds
- Programmable mute switch on EW-DX SKM-S lets you customize the device depending on your professional needs
- Function buttons control all the transmitter settings directly from handheld microphone
- Clear and easy focused user interface with OLED display enable at-a-glance settings monitoring
- Network enabled for control with Sennheiser Control Cockpit/media control system through a number of 3rd party modules
- 2 channel half rack (9.5’)
- Up to 88 MHz switching bandwidth
- PoE IEEE 802.3af Class 3
- Equidistant Channel Spacing: 146 channels in standard mode; 293 channels in Link Density Mode
- Ethernet connectivity (IPv4 and IPv6)
- Secure AES 256 encryption
- External PSU 12V/1A
- All-metal housing
- 10mW RF power with up to 100m/328ft working range
- Charging contacts for in-device charging with CHG 70N
- Persistent eInk display - parameters visible on screen even when device is not powered on
- Extended runtime with lithium-ion batteries - up to 12 hours operation time
- Standard capsule interface - compatible with a wide range of Sennheiser and Neumann capsules
- Mic input trim control
Ideal for vocals, the EW-DX 835-S SET from Sennheiser is a wireless handheld microphone system. This set includes two EW-DX SKM-S handheld transmitters, two MMD 835 cardioid dynamic microphone capsules, one EW-DX EM 2 two-channel rackmount receiver, and two BA 70 rechargeable batteries.
The handheld transmitters include built-in mute switches.
- System
- Audio Link Frequency Ranges
- Q1-6: 470.2 - 526 MHz
- R1-6: 520 - 576 MHz
- V5-7: 941.7 - 951.8 MHz & 953.05 - 956.05 MHz & 956.65 - 959.65 MHz
- Bluetooth® Low Energy (BLE) frequency range: 2402 - 2480 MHz
- Audio Frequency Response: 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
- Audio THD: ≤ -60 dB for 1 kHz @ -3 dBfs input level
- Dynamic Range: 134 dB
- System Latency: 1.9 ms
- Operating Temperature: 14°F to 131°F (-10°C to 55°C)
- Relative Humidity: 5 - 95% (non-condensing)
- EW-DX EM 2 (Rack Receiver)
- Input Voltage: 11 - 13 V &9107; or PoE IEEE 802.3af Class 0 (CAT5e or higher)
- Input Current: ≤ 1 A
- Transmit Power (radiated): BLE: max. 10 mW EIRP
- Audio Output Power: 18 dBu max
- Headphone Output: 2x 70 mW @ 32Ω
- Ethernet
- RJ-45 socket, IEEE802.3
- 100Base-TX (half+full duplex)
- 10Base-T (half+full duplex)
- (CAT5e or higher)
- Dimensions: 8.35" x 1.73" x 7.44"
- Weight: approx. 2.2 pounds (without antennas and power supply)
- EW-DX SKM-S (handheld transmitter)
- Input Voltage: 2.0 - 4.35 V
- Input Current: < 300 mA
- Power Supply: 2 AA batteries 1.5 V (alkali manganese) or BA 70 rechargeable battery pack
- Occupied Bandwidth: 200 kHz
- Transmit Power (radiated)
- Audio link: 10 mW ERP
- (Range Y1-3: 12 mW ERP)
- BLE: max. 10 mW EIRP
- Dimensions (ø x l): 1.97" x 10.55"
- Weight: 0.67 pounds
- MMD 835 (microphone module)
- Transducer Principle: dynamic
- Sensitivity: 2.1 mV/Pa
- Sound Pressure Level: 154 dB SPL
- Pick Up Pattern: cardioid
