- Transducer TypeCondenser
- Polar PatternSupercardioid
- Frequency Response50 Hz - 20 kHz
- Output Impedance47 Ω
- Output Impedance5 Ω
- Sensitivity (open circuit voltage, @ 1 kHz, typical)
- 0 dB Gain: -35.8 dBV/Pa [1] (16.2 mV)
- +30 dB Gain: -5.8 dBV/Pa [1] (512.9 mV)
- Maximum SPL
- 0 dB Gain Setting, 1 kHz at 1% THD [2], 1000 Ω load
- 129.2 dB SPL
- Signal-to-Noise Ratio [3]
- +30 dB Gain Setting
- 78.4 dB
- Self Noise
- equivalent SPL, A-weighted, typical, +30 dB Gain Setting
- 15.6 dB SPL-A
- Recording FormatWAV, 24-bit, 48 kHz Sampling Rate
- HousingCast aluminum
- Power Requirements2 AA batteries (Alkaline, NiMH, Rechargeable Li-Ion)
- Connector Type3.5 mm (1/8") dual mono, Unbalanced
- Weight215 g (7.6 oz.)
- Notes
- [1]1 Pa=94 dB SPL
- [2]THD of microphone preamplifier when applied input signal level is equivalent to cartridge output at specified SPL
- [3] S/N ratio is the difference between 94 dB SPL and equivalent SPL of self noise, A-weighted
