• Tascam MM-2D-X 2-Channel Mic/Line I/O Dante Converter with DSP Mixer
1 1

TASCAM MM-2D-X 2-Channel Mic/Line I/O Dante Converter with DSP Mixer

TASCAM MM-2D-X 2-Channel Mic/Line I/O Dante Converter with DSP Mixer

SoundPro Item: 38922 | Part Number: MM-2D-X

$749.00
$899.00 $749.00
Your Price Sold out
MSRP: $899.00 | MAP: $749.00

Usually ships in 5-7 business days

  • 2-channel mic/line input with phantom power (+48v) support
  • Supports remote mic gain control
  • 2 line output
  • 4 Dante input/output
  • Supports PoE (Power over Ethernet)
  • Up to 24bit/96kHz
  • Includes a variety of DSP functions for optimal use in different scenes/environments (Output effects, 6 in/4 out matrix mixer)
  • Supports Dante daisy chain; this allows two Dante Compact Processor models to be connected without a network switch
  • Compatible with Dante Domain Manager and Dante AES67 Mode
  • Flexible scene preset function allows to work in different area situations (Up to 50 presets)
  • Timer event function allows to automatically switch scenes at a specified time (planned to be compatible on a future version update)
  • 2 types of user control software available for Windows/Mac/iOS/Android devices:
  • For integrators: input/output routing selection, DSP/design/scene settings of the complete system, etc.
  • For end-users: simple app design for only the necessary functions such as area volume settings, etc.
  • Remote control via Dante
  • Half-rack mountable size
  • Equipped with indicators that show LAN/Dante connection status and sample rate
  • Equipped with signal indicators that monitor line input/output signals
  • Configurable reference level (via remote control only)
Log in or register for YOUR best price

The MM-2D-X is a compact converter that converts 2-channel mic/line input/output signals into Dante signals. With half the size of a standard 1U rack, the MM-2D-X is suitable for different Dante systems as an exquisite analog output unit. The built-in DSP mixer enables small scale systems to fully perform with a variety of input/output models the TASCAM Dante Compact Processor Series offers. MM-2D-X supports up to 96kHz/24bit and uses XLR connectors for analog mic/line input/output.

View full details
  • Formats and channels44.1/48/88.2/96kHz,16/24-bit, 2 channels
  • Input/output ratings
    • DATA/DATA+PoE connectors
      • Connector: RJ-45
      • Transmission protocol: Dante
      • Gigabit Ethernet standard: 1000BASE-T (IEEE 802.3ab)
      • Cables: category 5e or faster STP cables
    • ANALOG IN connectors
      • Connector: XLR-3-31 (1: GND, 2: HOT, 3: COLD)
      • Minimun input level: -74 dBu
      • Maximum input level: +26 dBu
      • Input impedance: 2.0 kΩ or higher
    • ANALOG OUT connectors
      • Connector: XLR-3-32 (1: GND, 2: HOT, 3: COLD)
      • Nominal output levels
        • +4 dBu: (when Ref. Level not -9 dBFS)
        • +6 dBu: (when Ref. Level set to -9 dBFS)
      • Maximum output level (switchable)
        • +15 dBu (Ref. Level: -9 dBFS)
        • +18 dBu (Ref. Level: -14 dBFS)
        • +20 dBu (Ref. Level: -16 dBFS)
        • +22 dBu (Ref. Level: -18 dBFS)
        • +24 dBu (Ref. Level: -20 dBFS)
      • Output impedance: 200Ω or lower
  • Power
    • PoE class: 0
    • TASCAM PS-P1220E AC adapter (sold separately)
  • Power consumption6W
  • Dimensions (WxHxD, including protrusions)214x44.45x136.1mm
  • Weight878 g
  • Operating temperature range0°C-40°C
  • Audio performance
    • MIC IN → DANTE OUT
      • Mic amp EIN (equivalent input noise): -125 dBu (150Ω, 22kHz LPF+A, JEITA)
      • Frequency response
        • +/-0.5 dB: 20 Hz - 20 kHz(44.1/48kHz sampling frequency, JEITA)
        • +/-0.5 dB: 20 Hz - 40 kHz(88.2/96kHz sampling frequency, JEITA)
      • Distortion (THD+N): 0.005 %(when -1 dBFS input, 44.1/48/88.2/96kHz samplingfrequency, JEITA)
      • S/N ratio: 105 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
      • Crosstalk: 100 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
      • Dynamic range: 105 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
    • DANTE IN → LINE OUT
      • Frequency response
        • +/-0.5 dB: 20 Hz - 20 kHz(44.1/48kHz sampling frequency, JEITA)
        • +/-0.5 dB: 20 Hz - 40 kHz(88.2/96kHz sampling frequency, JEITA)
      • Distortion (THD+N): 0.005 %(when -1 dBFS input, 44.1/48/88.2/96kHz samplingfrequency, JEITA)
      • S/N ratio: 105 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
      • Crosstalk: 100 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
      • Dynamic range: 105 dB (44.1/48/88.2/96kHz sampling frequency, JEITA)
      • Note: JEITA indicates compliance with JEITA CP-2150
