- Battery Type(2) AA Alkaline or 2 x AA NiMH
- Current Consumption52mA nominal
- Channels17, accessed via seek button in battery compartment
- Operating Frequencies72.1, 72.2, 72.3, 72.4, 72.5, 72.6, 72.7, 72.8, 72.9, 74.7, 75.3, 75.4, 75.5, 75.6, 75.7, 75.8, 75.9 MHz*
- Intermediate Frequency75 kHz
- FM Deviation75 kHz
- De-Emphasis75 µS
- LED Indicatorpower (green), low battery (flashes green)
- AFC Range± 120 kHz
- Sensitivity2 µV at 12 dB Sinad with squelch defeated
- Input Overload100 mV
- Frequency Response200 - 15,000 Hz
- ModulationFM, +/- 75 kHz peak deviation
- Signal-to-Noise Ratio65 dB min @ 100 uV
- Receive AntennaIntegral with earphone/headphone cord
- Audio Output35 mW max, peak into 16 ohms
- Output Connector3.5 mm stereo/mono phone jack
- EarphoneEarbud-type with foam cushion, 3.5 mm plug, 32 Ω
- Auto Shut-OffEnters sleep mode after approx 6 mins of no RF signal
- ApprovalsFCC, Industry Canada, RoHS, WEEE
- WarrantyLifetime PLUS Limited Warranty, 90 Days on most accessories
