The versatile MSP3 reference monitor has been renewed as the MSP3A, featuring a new Twisted Flare Port that delivers clearer bass from a simpler, more beautiful design.
With a 22-watt built-in amplifier, the MSP3A offers faithful sound reproduction, and like its predecessor, has a variety of inputs and controls and is compatible with numerous optional support brackets.
The MSP3A is an ideal choice for small studios and post-production setups, as well as also for monitoring electronic instruments and surround reproduction.
Yamaha MSP3A Features
- Authentic Sound in A Compact Body
- Clear Bass from Unique Twisted Flare Port Technology
- Versatile Inputs and Controls
- Mounting points for ceiling and wall mounting brackets and mic stand adaptor options
- MSP3A 4-Inch Powered Studio Monitor1
- Power cord1
- Owner's manual1
- Speaker Type2-way powered speaker, Bass-reflex type (Twisted Flare Port)
- Frequency Response (-10dB)67Hz - 22kHz
- Components
- LF: 4" (10 cm) Cone
- HF: 0.8" (2.2 cm) Dome
- Crossover4kHz
- Output power22W
- Maximum Output Level (Measured peak, IEC noise@1m)99dB SPL
- Input sensitivityLINE 1 : -10 dBu, 10kΩ (RCA), LINE 2 : +4.0 dBu, 10kΩ (Combo)
- I/O ConnectorsLINE 1 : RCA, LINE 2 : Combo (XLR/TRS phone)
- IndicatorsPower ON (Green LED)
- Power requirementsMay vary depending on region : 120V 50/60Hz, 110 – 120V 50/60Hz, 230V 50/60Hz, 220 – 230V 50/60Hz, 220V 50Hz, 240V 50Hz
- Power consumption30W
- OthersLevel control (LINE1, LINE2); Tone control (LOW: -3.0dB - +3.0dB @100Hz, HIGH: -3.0dB - +3.0dB @10kHz)
- Dimensions (WxHxD)5-5/8x9-1/4x6-5/8" (144x236x166mm)
- Net weight7.9 lbs. (3.6kg)
- PackagingSingle
- Flying and mounting hardware2 x M5, Depth 15 mm (9/16")
- OptionsMic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-120 / BWS20-190, Ceiling bracket BCS20-150 / BCS20-210
