- Active or PassiveActive
- Power Rating (Watts) 100 watts, program (175 watts, peak)
- Measured Max SPL (C-Weighted, Max Hold) 116dB Cont. 122 dB Peak
- Frequency Response (Hz +/- 3dB) 47Hz-100Hz
- Crossover Frequency (Hz) 100 Hz lowpass
- Cabinet Configuration Bass Reflex
- Driver Configuration 2x8" LF woofer
- LF Driver(s) 8" Neo with 2" Voice Coil
- LF Impedance (Ohms)4 ohm Load (2x 8 ohm in Parallel)
- LF Protection Excursion, Voice Coil Thermal (RMS)
- LF Amplifier Type Class D
- Cooling Scheme Convection
- Power Cable Yes
- Power Switch Yes
- Power Consumption 100VA
- Inputs 2x (L&R) XLR / ¼-inch Combi-jack, BluetoothTM, 3.5mm Stereo,
- Outputs 2x XLR (L&R)High Pass Out, XLR Full Range Mix Out
- Level Controls Sub Level
- Limiter Excursion, Thermal (RMS), Clipping
- LED Indicators Activity, 4x Battery Level, Charging Status, Bluetooth
- Enclosure Materials 12mm Birch Plywood
- Stacking Feature Interlocking Rubber Feet (top/bottom)
- Covering / Finish Paint
- Dimensions (DWH xbackW, inches) 21.625 x 14.750 x 12.5
- Dimensions (DWH xbackW, cm) 55 x 37.5 x 32
- Weight (lbs/kg) 30/13.6
