- Power Rating (Watts) 560 watts program (300 Low, 240 Mid, 20 High)
- Max SPL (dB) 126dB Peak
- Frequency Response (Hz +/- 3dB) 38 - 20K (Hz +/-3dB)
- HF Dispersion (°H x °V) 110 x 90
- Power Consumption While Charging 55 watts (battery fully discharged and unit idling)
- Speaker Configuration - LF 10 inch Neodymium Woofer
- Speaker Configuration - MF 4 X 3-inch Neodymium Full Range Drivers
- Speaker Configuration - HF 0.75" Exit Neodymium Compression Driver
- Inputs 6
- Channel 1 Input XLR / ¼-inch Combi-jack
- Channel 1 Controls Level, Input Type, Voicing, Reverb
- Channel 2 Input XLR / ¼-inch Combi-jack
- Channel 2 Controls Level, Input Type, Voicing, Reverb
- Channel 3 Input XLR / ¼-inch Combi-jack, 1/8-inch TRS Stereo Jack
- Channel 3 Controls Level, Input Type, Voicing, Reverb
- Master Volume Control Master Level, Sub Level
- Link In/Out (type / configuration) XLR (Male and Female)
- LED Indicators Power, Bluetooth™, 4x Battery Level, Charging Status, Channel Clip, Channel Select, Input Type, Voicing, Reverb
- Dimensions (DWH xbackW, inches) 15.82 x 12.50 x 21.87
- Dimensions (DWH xbackW, cm) 40.17 x 31.61 x 55.56
- Weight (lbs/kg) 40.5/18.4
