ChamSys GeNetix Wall Mount DMX Node PoE

ChamSys GeNetix Wall Mount DMX Node PoE

SoundPro Item: 146871 | Part Number: GENETIXGW2IUS

Regular price $395.00
Regular price $440.00 Sale price $395.00
Your Price Sold out
MSRP: $440.00 | MAP: $395.00

Usually ships in 5-7 business days

  • Fits U.S. Single Gang Back Boxes
  • PoE Power Reduces Local Wiring Needs
  • Two RDM DMX Ports For Flexible I/O
  • Art-Net And sACN Network Support
  • Web Server Allows Remote Setup
  • Black Or White Faceplates Included

The ChamSys GENETIXGW2IUS is a two-port wall mount DMX node built for installed lighting systems that need a clean in-wall endpoint with network-based control. Designed to fit a standard U.S. single gang back box, it provides a practical way to place DMX where it is needed in theaters, houses of worship, hospitality spaces, and other permanent venues without relying on surface-mounted interfaces.

This GeNetix Wall Mount Node 2 supports both Art-Net and sACN, making it suitable for modern distributed lighting networks. Its two RDM Direct DMX ports support input or output operation, giving designers and technicians added flexibility when integrating control points into fixed infrastructure. Configuration can be handled from ChamSys consoles, through the built-in web server, or over Art-Net, which helps streamline deployment and ongoing system adjustments.

PoE power simplifies installation by reducing the need for local power at the wall location. The unit is supplied with interchangeable black and white faceplates to better match room aesthetics, and it is offered in versions with either male or female DMX ports. This model does not unlock demo mode on MagicQ PC systems.

View full details

Specifications

Hardware
RDM Direct DMX Ports
2
Network Ports
1 (punchdown connector)
PoE Powered
Yes
DMX Port Options
Available with either Male or Female DMX Ports
Faceplates Included
Black and White Face Plates
Back Box Fit
U.S.A single gang box
Software
Art-Net/sACN
Yes
ChamNet Support
Yes
Configurable DMX Timings
Yes
Web Server
Yes
DMX Redundancy Support
Yes
Unlock's 'demo mode' MagicQ PC Systems
No
Dimensions
Width
70mm (2.76 inches)
Depth
37.5mm (1.48 inches)
Height
115mm (4.53 inches)
Weight
0.15KG (0.33lb)
