Lectrosonics SNA600a Adjustable Dipole Antenna
Lectrosonics SNA600a Adjustable Dipole Antenna

Lectrosonics SNA600a Adjustable Dipole Antenna

(No reviews yet)
SoundPro Item: 71731
MPN: SNA600a
Call for Info
Add to Wish List

Account manager
Contact an Account Manager for your personalized price

The SNA600 antenna from Lectrosonics is a versatile tool for use with wireless microphone receivers or IFB transmitters. The center frequency of its 100 MHz bandwidth is tunable from 550 to 800 MHz. The frequency is set by adjusting the dipole elements using the scale printed on the body of the antenna. The elements fold for storage.

Lectrosonics SNA600a Features

  • Use with wireless microphone receivers or IFB transmitters
  • Adjustable elements tune center frequency from 550 to 800 MHz
  • Foldable for storage
  • SWR less than 2:1 over 100 MHz bandwidth
  • Built in balun matched to 50 Ω BNC connector
  • Can be used with antenna power enable on receiver or multicoupler
  • SNA600a adjustable dipole antenna1
  • 3/8" x 16 threaded socket and stud1
  • Mounting strap1
  • Impedance50 Ω
  • Connector TypeBNC
  • SWRless than 2:1 at +/-50 MHz
  • 3dB Bandwidth150 MHz
  • Usable Frequency Range465 to 850 MHz
  • Gain2.17dBi (isotropic) or 0 dBd (referenced to a dipole)
  • Antenna Power Blockingcapacitive coupling for use with DC power on cable
  • Dimensions
    • Length: 7"
    • Width: 7-11" extended depending on frequency (1" folded)
    • Thickness: 1"
    • Weight: 3.5 oz

In The Box
