Part of the ZLX G2 series of loudspeakers, the ZLX-12P-G2 from Electro-Voice is a 12", two-way powered speaker.
More about Electro-Voice ZLX G2 Loudspeakers
The ZLX G2 loudspeaker series packs stellar sonic punch and pristine intelligibility into a compact, versatile build that helps you take control of your sound no matter what your gig. Featuring EV-engineered custom drivers housed in an innovative cabinet design, the ZLX G2 delivers renowned sound quality and rugged reliability.
Building on the original series’ iconic features, this next iteration of ZLX offers models in three different sizes, including a brand new 8” size as well as 12” and 15”. These two-way speakers are available in both powered and passive versions. Bluetooth®-enabled options are also available for wireless audio streaming.
Powered by Dynacord, ZLX G2 boasts built-in digital mixers with high-quality effects, customizable presets, stereo streaming, AFS, ducker, and PEQ. Best-in-class processing is made possible via QuickSmartDSP, while intuitive controls allow for easy setup and in-the-moment adjustments on its large color LCD.
ZLX G2 offers increased output and extended frequency response using its high-efficiency 1000W Class-D power amplifier. EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading. All ZLX G2 features are packed into a freshly designed, ergonomic multi-position enclosure made for simpler, easier setup and durable portability.
You can pole-mount the ZLX G2 loudspeakers or set them on the floor to use them as monitors. In addition, the ZLX-BRKT wall mount bracket is available as a permanent installation option. Other accessories include the ZLX padded covers for protecting your speakers while they’re in storage or on the go.
Electro-Voice ZLX-12P-G2 Features
- LCD display and 1-knob DSP control with presets for precise and speedy setup
- Input level meters and independent amplifier control to ensure optimal gain structure
- Front LED for “power on” and “limit” indication
- Patented split-baffle design for superior driver time alignment
- Durable composite construction with innovative hi/lo grip design for easy pole mounting
- ZLX-12P-G2 Data Sheet1
- Frequency Response65 Hz – 18 kHz [1]
- Frequency Range50 Hz – 20 kHz [1]
- Maximum SPL126 dB
- Coverage (Hort. x Vert.) 90° x 60°
- Power Rating1000W
- LF Transducer300 mm (12”) Woofer
- HF TransducerDH-1K
- Connectors (2) XLR/TRS Combo Jack, (1) 3.5 mm Input, and (1) XLR link Output
- EnclosurePolypropylene
- Grille18 Gauge Steel with Black Powder Coat
- Dimensions (HxWxD) 610x356x356mm (24x14x14”)
- Net Weight15.6 kg (34.3 lbs)
- Shipping Weight19 kg (41.8 lbs)
- Notes[1] Using MUSIC DSP preset
