Shure MXWNCS2 2-Channel Networked Charging Station

Networked charging station allows handheld, bodypack, and boundary transmitters to charge in 1 port for each. Features include charge status indicators, charge status monitoring, transmitter linking, and overcharge protection to extend life cycles.

Shure MXWNCS2 Features

• Versatile microphone docking: MXWNCS 2 allows handheld, bodypack and boundary transmitters to charge in one port each
• Charge status indicators: 5-segment LED’s on the unit display charge status individually for every docked microphone
• Remote charge status monitoring: Ethernet connection to the system enables remote monitoring of battery charge status in hours and minutes via the control software or third party control systems
• Easy transmitter linking: Assign docked wireless microphones to channels on an Access Point Transceiver by simply pressing “link”
• Rapid charge times: Reaches 50% charge in one hour and fully charges transmitters in two hours
• Overcharge protection: Smart recharging circuitry safeguards against battery damage and extends life cycles
• MXWNCS2 attaches to wall or podium with included mount plate

• MXWNCS2 2-Channel Networked Charging Station1

• Charging Time
  • SB902: 50%=1.5 hour; 100%=3 hours; High Efficiency Mode=4-5 hours
  • SB905: 50%=2.5 hour; 100%=5 hours; High Efficiency Mode=5-6 hours
• Network Interface10/100 Mbps Ethernet
• Power Requirement
  • 15 V DC @ 3.33 A
  • maximum, supplied by external power supply (tip positive)
• HousingMolded Plastic, Cast Zinc
• Dimensions (HxWxD)1.9x4x6.1 in. (48x102x154 mm)
• Weight1.8 lbs (0.8 kg)
